Electric Flange Butterfly Valve

Product name：Electric Flange Butterfly Valve
Item：DHDV-E
Details：
Product name: Electric Flange Butterfly Valve Model:DHDV-E Nominal diameter: DN15~DN200 Body material: WCB, 304,316, 316L Connection: Flange Pressure range: PN1.6~4.0MPa Structure: Float ball core Seat sealing: PTFE:-30~180℃， PPL：-30~250℃ Core material: 304, 316, 316L Stem material: 304 Applicable medium: water, oil, steam,etc Leakage: zero leakage Return differential: ±2.5%
