2/2 Way RSPS-J Series Solenoid Valve,G1/2″~G2″
Technical Specification
Medium:Steam,Hot water,Air,Oil(below 20cst)
Temperature:-5～180℃
Mode of action:Semi-direct lift type
Pressure:Normally Closed(N/C)10bar
Body material:Stainless
Sealing material:PTFE
Protection class:IP54
Options
EPDM(E):suitable to water,hot water,gas,freon,the MAX120℃;The coil is plastic coil.IP65.
Viton(V):suitable to hot water,acid,alkali,chemical salt,oil and hydrocarbon;the MAX.150℃;;The coil is plastic coil.IP65.
The structure is the same as RSPS series
Parameters
|
Model |
RSPS
-J-15 |
RSPS -J-20 |
RSPS -J-25 |
RSPS -J-32 |
RSPS -J-40 |
RSPS -J-50 |
RSPS -J-25F |
RSPS -J-32F |
RSPS -J-40F |
RSPS -J-50F |
|
|
G connection |
1/2″ |
3/4″ |
1″ |
11/4″ |
11/2″ |
2″ |
1″ |
11/4″ |
11/2″ |
2″ |
|
|
Orifice Size |
mm |
15 |
20 |
25 |
32 |
40 |
50 |
25 |
32 |
40 |
50 |
|
Cv Value |
|
4.8 |
8.5 |
14 |
20 |
31 |
51 |
14 |
20 |
31 |
51 |
|
L |
mm |
70 |
72 |
98 |
116 |
120 |
148 |
128 |
157 |
157 |
201 |
|
H |
mm |
131 |
137 |
158 |
177 |
181 |
207 |
166 |
220 |
240 |
240 |
|
H1 |
mm |
117 |
122 |
139 |
153 |
521 |
171 |
117 |
152 |
168 |
162 |
|
power |
220V-230V AC/50-60HZ 22VA |
220v-230VAC/50-60HZ 30VA |
220V-230V AC/50-60HZ 38VA;110V-120V AC/50-60HZ 35VA;DC24V 56W;Range:±10% |
||||||||
|
Medium temperature |
℃ |
-5~180℃ |
|||||||||
|
Pressure |
bar |
0~10 |
|||||||||
